PFS3010-8ET-65

8-Port Gigabit Switch (Unmanaged)

> Layer 2 unmanaged access switch
> All gigabit ethernet ports
> Lightning protection
> Plug and play
> Adopts metal enclosure
> Good heat dissipation

106.89 ₼

Sayı

Daha ətraflı məlumat

0 şərh | Şərh yaz

Açıqlama Yükləmələr Şərhlər (0)

Hardware properties
Data transfer port	8 PoE ports with Base-TX 10/100 Mbps 2 Cascading ports with Base-TX 10/100 Mbps
PoE
PoE budget	Port 1-8 ≤ 30W, all POE budget ≤ 65W
PoE Standard	IEEE802.3af, IEEE802.3at
POE Pin Assignment	PoE: 1, 2, 4, 5(V+), 3, 6, 7, 8(V-)
Performance
Switching capacity	2.0 Gbps
Packet forwarding speed	1.49 Mpps
MAC Table size	2 K
Jumbo Frame	2048 bytes
Communication Standard	IEEE 802.3, IEEE 802.3u, IEEE 802.3X
Certificates
Certificates	CE:EN60950; FCC
Environment
Operating temperature	-10 ° C to + 55 ° C (-14 ° F-131 ° F)
Operating humidity	10 % – 90 %
Electrical properties
Power supply	AC100 – AC240V
Power consumption	Idling:1.0 W Full load:65 W
ESD	Air discharge:8kV Contact discharge:6kV
Lightning protection	General mode:6kV Differential mode:4kV
General information
Sizes	242.5 mm × 122.9 mm × 35.0 mm (9.55 "× 4.84" × 1.38")
Net Weight	0.76 kg (1.68 lb)
Gross Weight	1.3 kg (2.87 lb)
